TEMPLATE SYSTEM
CONSMOS 7 STAR FILM FACE PLYWOOD
Product | Film faced plywood | Core | Full Birch | |||||
Film | Dynea Brown/Black film | Film Grammage | 120g/m2 | |||||
Size | 1220*2440*18mm11525*3050*18mm 1250*2500*18mm1525*1525*18mm | Glue | Dynea Phenolic WBP Glue | |||||
ON. | Property | Unit | Standard | Value of Test | Result | |||
1 | Moisture Content | % | EN 322 | 8 | pass | |||
2 | Thickness Tolerance | mm | ±0.5 | ≤±0.3 | pass | |||
3 | Glue Bond Strength | Single Test Bond Strength Value | Mpa | EN 314 | Max. | 3.58 | pass | |
Min. | 2.86 | pass | ||||||
Average Wood Failure | % | / | 98 | pass | ||||
4 | Bending Strength | Longitudinal | Mpa | EN 310 | 93.22 | pass | ||
Transverse | 62.18 | pass | ||||||
5 | Elastic Modulus | Longitudinal | Mpa | 9950 | pass | |||
Transverse | 7825 | pass | ||||||
6 | Density | kg/cbm | EN 323 | 700 | pass | |||
7 | Cycle Life | 25-60 reusing times decided by the usage cleaning and storing after each time using) | ||||||
Product advantage:
This product is a luxury grade plywood, used full birch core, Phenolic glue, boiling water resistant 72 hours, 3 times hot press and sanding make this product the best quality building board in the market, can be reused 25-60 times
