TEMPLATE SYSTEM
CONSMOS 1 STAR FILM FACE PLYWOOD
Product Introduction
Product | Film faced plywood | Core | Finger Joint Core | |||||
Film | Brown/Black | Film Grammage | 220g/m2 | |||||
Size | 1220*2440*18mm | Glue | WBP Melamine | |||||
ON. | Property | Unit | Standard | Value of Test | Result | |||
1 | Moisture Content | % | EN 322 | 12 | pass | |||
2 | Thickness Tolerance | mm | ±0.5 | ≤±0.5 | pass | |||
3 | Glue Bond Strength | Single Test Bond Strength Value | Mpa | EN 314 | Max. | 1.58 | pass | |
Min. | 0.86 | pass | ||||||
Average Wood Failure | % | / | 80 | pass | ||||
4 | Bending Strength | Longitudinal | Mpa | EN 310 | 49.56 | pass | ||
Transverse | 36.35 | pass | ||||||
5 | Elastic Modulus | Longitudinal | Mpa | 6012 | pass | |||
Transverse | 4839 | pass | ||||||
6 | Density | kg/cbm | EN 323 | 560 | pass | |||
7 | Cycle Life | 2-5 reusing times decided by the usage (cleaning and storing after each time using) | ||||||
Product advantage：
This product has the cheapest price, basically no defects, no distortion on the surface, and can meet the daily use
